EURORACK … 19″ subrack system
Eurorack is a 19 inch subrack system designed for mounting plug-in modules and printed circuit boards. Dimensions conform to DIN 41494 parts 1 and 5, internal dimensions conform to DIN 41494 part 2 for plug-in modules and printed circuit boards.
Sideplates are made from 2,5mm aluminium alloy satin anodised to BS1615-AA10. Horizontal rails are extruded from aluminium alloy, guide location holes are punched on a 5,08mm pitch and are printed 1-84, 84-1 for guide rail alignment. To provide horizontal rails with a positive location, the sideplates have semi-shears which locate against each end of the rail. The sideplates are profiled at the rear to protect connector pins and has fixing holes to accept vertical bus bars or full width rear cover.
3U x 84HP Type 1 DIN 41612
|
Ref
|
Description
|
Qty
|
|
1
|
Sideplate |
2
|
|
2
|
T-Front Plate |
2
|
|
3
|
Front Horizontal Rail |
2
|
|
4
|
Connector Mounting Rail |
2
|
| Screws M5 x 12mm, Pan Hd |
8
|
* Indicates alternative positions
3U x 84HP Type 2 MOTHERBOARD
|
Ref
|
Description
|
Qty
|
|
1
|
Sideplate |
2
|
|
2
|
T-Front Plate |
2
|
|
3
|
Front Horizontal Rail |
2
|
|
4
|
Rear Horizontal Rail |
2
|
| Screws M5 x 12mm, Pan Hd |
8
|
* Indicates alternative positions
